Drafting Services Limited
Founded in 2016 and based in Edinburgh, Scotland, Drafting Services Limited provides comprehensive steel detailing services. We specialise in supporting steel fabrication companies across industrial, commercial, and residential sectors. Our experienced team is equipped to handle projects of any scale, ensuring precision and reliability for your fabrication needs.
Services
Liaison with Engineers & Architects
We proactively coordinate with engineers and architects to clarify design intent and ensure seamless project integration.
3D Model of the Steel Structure
We develop a precise and detailed 3D model representing the complete steel structure for visualization and data extraction.
General Arrangement Drawings
We generate clear General Arrangement (GA) drawings illustrating the overall layout, member locations, and main dimensions of the steel structure.
3D Views Drawings
We produce illustrative 3D view drawings extracted from the model to provide enhanced visualization of complex areas or connections.
Steel Fabrication Drawings
We issue comprehensive fabrication drawings (shop drawings) with all necessary details required for the accurate manufacturing of individual steel members and assemblies.
Parts and Erection Drawings
We supply detailed drawings outlining individual parts alongside clear erection plans guiding the safe and efficient assembly of the steel structure on site.
Parts, Cutting, Bolts lists
We generate accurate reports detailing all individual parts, material cutting requirements (like CNC data), and necessary bolt summaries for procurement and assembly.
BIM Models
We develop data-rich Building Information Models (BIM) to facilitate enhanced project coordination, clash detection, and information management throughout the project lifecycle.
